CS692 ATEN 宏正 2端口 USB HDMI带线式KVM(1.2米x2), 支持2.1音效
编号:CS692-at-z
品牌:ATEN   [查询该品牌全部商品]
单位:个
积分:0
重量:410 克
规格:
型号:
CS692 USB HD音频/视频KVM多电脑切换器可通过单一USB键盘、USB鼠标及HD显示器控制端操作2台HD接口电脑。该创新产品提供了完整的HDMI功能、USB 2.0接口设备分享(通过附加的USB鼠标连接端口)、及固件更新的功能,
CS692带领带线式KVM产品在技术面又向前迈进了一大步。

CS692整合了HDMI功能、方便的USB 2.0接口设备分享、游戏键盘支持以及操作简易的特性,为使用者提供多项桌上型多媒体应用的先进技术。
商品售价:¥0.00
订购数量:
订购 加入收藏

浏览 (2616) | 评论 (0) | 评分(0)
商品介绍
详细参数



2端口USB HD音频/视频KVM多电脑切换器

 Zoom In CS692 USB HD音频/视频KVM多电脑切换器可通过单一USB键盘、USB鼠标及HD显示器控制端操作2台HD接口电脑。该创新产品提供了完整的HDMI功能、USB 2.0接口设备分享(通过附加的USB鼠标连接端口)、及固件更新的功能,
CS692带领带线式KVM产品在技术面又向前迈进了一大步。

CS692整合了HDMI功能、方便的USB 2.0接口设备分享、游戏键盘支持以及操作简易的特性,为使用者提供多项桌上型多媒体应用的先进技术。


功能特点:


  • 一组配备HD显示器的控制端管理两台HDMI电脑或设备
  • 兼容于HDMI及HDCP规格
  • 可通过外接式切换按键、热键及USB鼠标切换电脑
  • 支持音频 - 具备重低频响应能力,可支持2.1立体环绕声道系统
  • 电脑及音频功能独立切换–一台电脑操作KVM设备,另一台针对音频设备做控制
  • 支持多平台–Windows, Linux, Mac
  • 设计精巧,内建多合一线缆(2 x 1.2 m)
  • 高视频分辨率–最高可达1920 x 1200; 1080p
  • 兼容于LCD宽显示器
  • 视频动态同步显示技术(Video DynaSync™)–ATEN独家技术能避免开机会产生的问题,并在切换连接端口时保持最佳视频显示分辨率
  • 电源开启侦测–若其中一台电脑电源关闭,CS692会自动切换至另一台电源开启的电脑
  • 支持游戏及多媒体键盘
  • 支持多功能的无线键盘与鼠标
  • 控制端鼠标仿真/by pass功能支持大多数鼠标驱动程序与多功能鼠标
  • 支持与仿真Mac键
  • USB 2.0鼠标端口可用以连接USB Hub分享USB周边设备
  • 无需电源
  • 支持固件更新


连线图:

http://www.aten.com.cn/images/uploadImages/KVM-Switches/Cable-KVM-Switch/diagram/CS692-%E5%B8%A6%E7%BA%BF%E5%BC%8FKVM%E5%A4%9A%E7%94%B5%E8%84%91%E5%88%87%E6%8D%A2%E5%99%A8-dg-org.gif


技术规格

电脑连接数 2
控制端连接数 1
连接端口选择 外接式切换按键、鼠标、热键
接口 控制端 键盘 1 x USB Type A 母头(银)
显示器 1 x HD Type A
母头(黑)
鼠标 1 x USB Type A
母头(银)
扬声器 1 x Mini Stereo Jack
母头(绿)
麦克风 1 x Mini Stereo Jack
母头(粉红)
电脑端 键盘 2 x USB Type A 公头(紫)
显示器 2 x HD Type A
公头 (黑)
鼠标 2 x USB Type A 公头(黑)
扬声器 2 x Mini Stereo Plug
公头(绿)
麦克风 2 x Mini Stereo Plug
公头(粉红)
LED指示灯 电脑端 2 (绿)
线缆长度 电脑端 2 x 1.2 m
外接式切换按键 1.8 m
仿真功能 键盘/鼠标 USB
视频分辨率 1080p; 1920 x 1200
扫描区间 3,5,10,20秒(预设为5秒)
耗电量 DC 5V, 2.65W
作业环境 操作温度 0 - 50°C
储存温度 -20 - 60°C
湿度 0-80% RH, 无凝结
机体特性 外壳 塑料
重量

0.41 kg

尺寸
(长x宽x高)
6.70 x 8.20 x 2.65 cm
2-Port USB HDMI/Audio Cable KVM Switch
CS692
The CS692 HD USB KVM Switch links two HD-enabled PCs or devices to a single USB keyboard, USB mouse, and HD display console. The CS692 Switch takes a giant step forward from prior cable KVM models in the Petite series, by offering full HDMI functionality, USB 2.0 peripheral sharing (via a USB hub attached to the USB mouse port), and a firmware upgrade function that allows you to keep up with latest available versions.


Featuring an unbeatable combination of HDMI functionality, USB 2.0 peripheral sharing convenience, gaming keyboard support, and enhanced user-friendly operations, the CS692 allows users to keep up with the latest innovations in desktop multimedia applications.
ROHS Weee
Share   Add to Compare
Package Contents
1x CS692 2-Port USB HD Audio/Video KVM Switch with Remote Port Selector
1x User Instructions
2x Hotkey Stickers



 Features
 Diagram
 Specifications
 Applications
 Support and Download
One HD video console controls two HD-enabled PCs or devices
HDMI compatible; HDCP compatible
Computer selection via remote port selector, hotkeys, and USB mouse
Audio-enabled - full bass response provides a rich experience for 2.1 channel surround sound systems
Independent switching of the KVM and Audio focus - one computer has the KVM focus and the other the Audio focus*
Multiplatform support - Windows, Mac, Linux
Compact design, built-in all-in-one cables (2 x 1.2 m)
Superior video quality - up to 1920 x 1200; 1080p
Compatible with widescreen LCD monitors
Video DynaSync™ - exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports
Power on detection - if one computers is powered off, the CS692 will automatically switch to the other computer
Supports gaming and multimedia keyboards
Supports multifunction and wireless keyboards and mice
Console mouse port emulation/bypass feature supports most mouse drivers and multifunction mice
Mac keyboard support and emulation**
USB 2.0 mouse port can be used for USB hub and USB peripheral sharing***
Non-Powered
Firmware upgradable

Note: * HD audio through the HD monitor's built-in speakers cannot be switched independently.
** PC keyboard combinations emulate Mac keyboards. Mac keyboards work only with their own computers.
*** May require an additional power adapter. To use the USB 2.0 mouse port as a USB hub, you must first disable mouse emulation mode.
