商品详情
CS1794 ATEN 宏正 4端口 USB2.0 HDMI KVMP™切换器,SUN,MAC,支持音频(1.8米x4)
编号:CS1794
品牌:ATEN   [查询该品牌全部商品]
单位:个
积分:0
重量:530 克
规格:
型号:
CubiQ™ CS1794 USB 2.0 HDMI KVMP™多电脑切换器兼具独特的流线设计与创新功能,可充份满足当今多媒体SOHO环境的多元化需求。
CS1794整合4端口KVM多电脑切换器及2端口USB 2.0 Hub,该两款产品支持2台电脑之间或是其它设备如游戏机的HDMI信号切换,并让使用者从单一控制端分享USB接口设备。CS1794提供先进的独立切换功能,使用者可通过前端面板按键及键盘热键进行功能切换,该两款产品同时具备显示器动态同步显示技术(Video DynaSync™ technology),可保持最佳HDMI显示器显示分辨率。

商品售价:¥0.00
订购数量:
订购 加入收藏

浏览 (1705) | 评论 (0) | 评分(0)
商品介绍
详细参数

4端口USB 2.0 HDMI KVMP™多电脑切换器



CubiQ™ CS1794 USB 2.0 HDMI KVMP™多电脑切换器兼具独特的流线设计与创新功能,可充份满足当今多媒体SOHO环境的多元化需求。


CS1794整合4端口KVM多电脑切换器及2端口USB 2.0 Hub,该两款产品支持2台电脑之间或是其它设备如游戏机的HDMI信号切换,并让使用者从单一控制端分享USB接口设备。CS1794提供先进的独立切换功能,使用者可通过前端面板按键及键盘热键进行功能切换,该两款产品同时具备显示器动态同步显示技术(Video DynaSync™ technology),可保持最佳HDMI显示器显示分辨率。



CS1794整合数字音频功能,可让使用者体验高清晰度音效,例如Dolby True HD及DTS HD Mater Audio。CubiQ™ CS1794独特的KVM技术可大幅节省桌面空间,适用于家庭或办公室的多媒体应用环境。



功能特点:

  • 4端口HDMI USB 2.0 KVMP™多电脑切换器
  • 一组USB控制端可管理4台HDMI接口电脑及2台USB接口设备
  • 内建2端口USB 2.0 Hub; 完全兼容于USB 2.0规格
  • 通过前端面板按键及键盘热键,独立切换电脑、USB接口设备、及音频功能
  • 支持HDMI数字显示器 – 完全兼容于HDMI及HDCP
  • 支持Dolby True HD及DTS HD Master Audio
  • 高视频分辨率-支持480i, 480p, 720p, 1080i, and 1080p(HDTV)/1920 x 1200(DVI)
  • 电源开启侦测-若其中一台电脑电源关闭,CS1794会自动切换至下一台电源开启的电脑
  • 支持宽显示器分辨率
  • 支持跨平台- Windows 2000/XP/Vista、Linux及Mac
  • 控制端鼠标端口仿真/bypass功能支持多数鼠标驱动程序与多功能鼠标
  • 显示器动态同步显示技术-储存控制端显示器EDID(延伸显示辨识码),保持最佳显示器显示分辨率
  • 完整的键盘信号仿真,确保开机零失误
  • 支持及仿真Mac键盘*
  • 自动扫描功能可监控所有电脑及HDMI设备
  • 支持固件更新

    连线图:

    技术规格:

    电脑连接数 4
    连接端口选择 前端面板按钮 ; 热键
    界面 控制端 键盘 1 x USB Type A 母头 (黑;背板)
    显示器 1 x HDMI Type A 母头 (黑)
    鼠标 1 x USB Type A 母头 (黑;背板)
    扬声器 2 x Mini Stereo Jack 母头
    (绿;1x 前端面板,1x 背板)
    麦克风 2 x Mini Stereo Jack 母头
    (粉红;1x 前端面板,1x 背板)
    电脑端 键盘

    4 x USB Type B 母头 (白)

    显示器 4 x HDMI Type A 母头 (黑)
    鼠标 4 x USB Type B 母头 (白)
    扬声器 4 x Mini Stereo Jack 母头(绿)
    麦克风 4 x Mini Stereo Jack 母头(粉红)
    固件更新 1 x RJ-11 Female (Black)
    电源 1 x DC 电源插座
    USB 2.0 Hub 2 x USB Type A 母头
    (白;1x 前端面板,1x 背板)
    开关 选择 5 x 按钮
    LED 指示灯 音频 5 (绿)
    KVM 5 (橘)
    USB 连接 5 (绿)
    仿真功能 键盘/鼠标 USB
    视频分辨率 1080p (HDTV)/1920 x 1200 (DVI)
    扫描区间 1-99 秒 (预设为 5 秒)
    耗电量 DC 5.3 V, 3.2 W
    作业环境 操作温度 0–50°C
    储存温度 -20–60°C
    湿度 0–80% RH, 无凝结
    机体属性 外壳 金属 ; 塑料
    重量 0.53 kg
    尺寸
    (长 × 宽 × 高)
    26.50 x 7.30 x 4.50 cm

  • 4-Port USB HDMI KVMP™ Switch
  • CS1794
  • With its unique design and innovative features, the CubiQ™ CS1794 USB 2.0 HDMI KVMP™ Switch provides both style and functionality for today's multimedia SOHO environment. Combining a 4-port switch with a 2-port USB 2.0 hub, the CS1794 provides seamless HDMI signal switching between 4 PCs or other HDMI-enabled devices, such as gaming consoles, and allows users to share USB peripherals from a single console.
  • The CS1794 provides enhanced independent switching via front panel pushbuttons and keyboard hotkeys, and features Video DynaSync™ technology to ensure that HDMI display resolution is always optimized. With integrated digital audio, the CS1794 also allows users to experience high-definition sound, such as Dolby True HD and DTS HD Master Audio.
  • Ideal for multimedia applications in the home or office, the CubiQ™ CS1794 offers the ultimate in space-saving, streamlined KVM technology for the desktop.
  • ROHS Weee
  • Share   Add to Compare
  • Package Contents
  • 1x CS1794 USB 2.0 HDMI KVMP™ Switch
  • 4x Custom HDMI KVM Cable Sets
  • 1x Firmware Upgrade Cable
  • 1x Power Adapter
  • 1x User Instructions
  • Your cart ×
  • TOTALUSD$0.00
  • Shipping and discount codes are added at checkout.
  • Checkout
  •  Buy Now !
  •  Awards won by this product
  •  Features
  •  Diagram
  •  Specification
  •  Applications
  •  Support and Download
  • 4-port HDMI USB 2.0 KVMP™ Switch
  • One USB console controls four HDMI-interface computers and two additional USB devices
  • 2-port USB 2.0 hub built in; fully compliant with the USB 2.0 specification
  • Independent switching of KVM, USB peripheral, and audio focus via front panel pushbuttons and hotkeys
  • HDMI digital monitor support - fully compliant with HDMI 1.3a; also HDCP compliant
  • Dolby True HD and DTS HD Master Audio support
  • Superior video quality - supports 480i, 480p, 720p, 1080i, and 1080p(HDTV)/1920 x 1200(DVI)
  • Power on detection - If one of the computers is powered off, the CS1794 will automatically switch to the next powered-on computer
  • Supports widescreen resolutions
  • Multiplatform support - Windows, Linux,and Mac
  • Console mouse port emulation/bypass feature supports most mouse driver and multifunction mice
  • Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
  • Complete keyboard emulation for error-free booting
  • Mac keyboard support and emulation*
  • Auto Scan Mode for monitoring all computers and HDMI devices
  • Firmware Upgradable

  • * 1. PC keyboard combinations emulate Mac Keyboards
  •    2. Mac keyboards only work with their own computers
